LT401H
Application:Widely used in chemical, steel, construction, food, medicine and other fields. The product is suitable for high temperature working environment. Its super corrosion resistance makes it free from various corrosive liquid chemicals (sulfuric acid, Hydrochloric acid, sulfur reactants, etc.) erosion. The fully saturated nature of PTFE / PFA also makes it a good choice for tubes in the food and pharmaceutical industries
Reinforcement layer:2-4 layers of super high flexible steel wire
Outer layer:EPDM / FKM
Temperature range:-30 ℃ ~ + 220 ℃ (-22 ℉ ~ + 428 ℉)
Reference standard:EN12115
Customized scope:can customize 4 'and inner diameter of hose
SIZE |
I.D. |
W.P. |
B.P. |
(in.) |
(mm) |
(MPa) |
(MPa) |
3/16"-2 |
5 |
42 |
166 |
1/4"-2 |
6 |
40 |
160 |
5/16"-2 |
8 |
35 |
140 |
3/8"-2 |
9 |
33 |
132 |
1/2"-2 |
12 |
28 |
110 |
5/8"-2 |
16 |
25 |
100 |
3/4"-2 |
19 |
22 |
85 |
1"-2 |
25 |
17 |
65 |
1 1/4"-2 |
31 |
13 |
50 |
1 1/2"-2 |
38 |
9 |
36 |
2"-2 |
50 |
8 |
32 |
1/2"-4 |
12 |
50 |
166 |
5/8"-4 |
16 |
45 |
180 |
3/4"-4 |
19 |
42 |
168 |
1"-4 |
25 |
38 |
152 |
1 1/4"-4 |
31 |
33 |
130 |
1 1/2"-4 |
38 |
29 |
116 |
2"-4 |
50 |
25 |
100 |
