LT1002-A/LT1002-B
Applications：For general wash down service, using hot and cold water in paper mills and in food and dairy plants
Reinforcement：High tensile textile cords
Cover：White or green EPDM-heat, abrasion and ozone resistant
Working Pressure：Constant Pressure-10 Bar (150 PSI)
Temperature Range：-40° F(-40° C) to 248° F(+120° C)
| Specifications | ||||||
| Series | I.D. （in.） |
I.D. （mm） |
O.D. （in.） |
O.D. （mm） |
Max.W.P. (psi) |
W. （kg/m） |
| LT1002A/B-075 | 3/4 | 19 | 1.22 | 31 | 150 | 0.65 |
| LT1002A/B-100 | 1 | 25 | 1.46 | 37 | 150 | 0.80 |
| LT1002A/B-125 | 11/4 | 32 | 1.81 | 46 | 150 | 1.16 |
| LT1002A/B-150 | 11/2 | 38 | 1.97 | 52 | 150 | 1.35 |
